Key features & benefits

• Billet aerospace grade aluminium alloy provides high strength and light weight
• Highly optimised design for high stiffness & low weight
• Ventilated stainless steel pistons
• Differential piston diameters that minimise pad taper wear
• Ø27.0  / 31.8 / 38.1mm bore sizes
• 210 x 42mm mounting centres
• Semi ducting ready for customer cooling

Specifications

• Disc diameter range Ø378 – 380mm
• Disc thickness range 32 – 36mm
• Dry weight 2.66Kg (excluding pads)
• Pads: 25mm thickness options, 54mm radial depth, area 60.5cm2
