Key features & benefits

Billet aerospace grade aluminium alloy provides high strength and light weight
Differential piston diameters that minimise pad taper wear
Stainless steel or titanium pistons
180mm mounting centres
Ø28.6 / 31.8mm bore size

Specifications

Disc diameter range Ø330 – 355mm
Disc thickness range 30 – 32mm
Dry weight 2.02Kg Ti pistons (excluding pads)
Dry weight 2.16kg Steel pistons (excluding pads)
Pads: 25mm thick, 50.5mm radial depth, area 64.5cm2
