Key features & benefits

• Billet aerospace grade aluminium alloy provides high strength and light weight
• Differential piston diameters that minimise pad taper wear
• Stainless steel pistons as standard
• 2kg anti-knock back springs
• Hard stainless steel wear plates
• Bolted pad retainer to increase stiffness, remove retainer to change pads

Specifications

• Disc diameter range Ø355 – 390mm
• Disc thickness range 34 – 36mm
• Dry weight 3.1kg excluding pads
• Alcon pad reference: 4489, 18mm thick, 152mm long, 54mm deep, area 156cm2 per caliper
