Key features and benefits

Radial mounting for maximum rigidity and firm, consistent pedal
Aluminium pistons as standard, stainless steel pistons available as an option to reduce heat transfer to brake fluid
2kg anti-knock back springs
Pad retaining wire for fast pad change
Stainless steel fluid transfer pipe

Specifications:
Disc diameter range Ø250 – 280mm
Disc thickness range 22.9 – 25.4mm
Fluid inlet 3/8-24 UNF (-3) female
Dry weight 1.35Kg excluding pads
Alcon pad reference: 3451/42 pad shape, area 49.2cm2 or 3451/47 pad shape, area 56.0cm2, 14mm thick, 63.4mm long, area 49.2cm2
Technical Drawings CRR280 Calliper
